12V AC 110V-220V Display Digital Temperature Controller Multi-Function Temperature Thermostat Control Switch -55~120 Celsius(DC12V)

Thermostat Controllers12V AC 110V-220V Display Digital Temperature Controller Multi-function Temperature Thermostat Control Switch -55~120 Celsius-Description: This product uses single-chip control system + high-precision temperature probe, temperature control performance and temperature control accuracy is superior to similar products. This product three windows design, start value and stop value real-time display, and with intermittent work, timer switch machine and other functions, in the greenhouse cultivation, aquatic animal husbandry, room temperature control can be widely used, it is a good helper at home!-Specification: Product Name: High Precision Digital ThermostatSpecifications Model: XH-W1411Temperature range: -55 ~ +120 °Temperature measurement accuracy: ± 0.3 °Resolution: 0.1 °Temperature range: -19 ~ 99 °Control accuracy: 1 °Temperature probe: 1 meter waterproof probeSupply voltage: 220VApplicable environment: -25 ~ 55 degrees Humidity 20% -85% (no condensation)Output type: 10A Relay output-Use:1, the product of the in the home socket on the screen shows the temperature that the power has been properly connected2, the temperature control probe into the need to control the temperature of the place, according to the need to set the start and stop temperature3, the heating or cooling equipment power in the thermostat socket can be achieved on the temperature control-The operating instructions:If the temperature is in the interval after power-up, the output will be activated immediately and the set value will be stopped<;stop temperature: heating modeFor example, want to control the water to 60 degrees to stop, to 45 degrees and then start, then the start value should be 45, stop the value of 60Start temperature> Stop temperature: Cooling modeFor example, when the summer wants to control the greenhouse above 35 degrees to start the ventilation fan, when to stop at 32 degrees, then the start should be set to 35, stop setting to 32SET: function key / switch keyIn the boot state, press and hold SET 3 seconds to shut down, if the power off after the shutdown is still kept offIn the shutdown state, press SET once to boot, boot if the power is still turned onPress the SET once to switch between F-1 and F-3 in the normal temperature control stateF-1 Intermittent Operating Mode Unit Minute Left Start Minute Right Stop MinuteF-2 timer off the left hour the right minute minutes up to 99 hours 59 minutesF-3 regular boot left hour right minute minutes up to 99 hours 59 minutesTemperature correction: unplug the thermostat and hold the SET power on, enter the temperature correction function, the screen display --000 - can be corrected before the temperature on the basis of addition and subtraction temperature, the maximum range of -9.9 ~ +99, calibration completed RearReal-time temperature = pre-correction temperature value + correction valuePress and hold (start + -) to enter the self test functionPress and hold (stop + -) to turn on the settings-To restore the :If you set the error or set the confusion can hold down the stop 2 keys to start the settingsScreen display 88-888-88, buzzer flute soon, recovery is completeDefault start 25, stop 40 F-1 01-10 F-2 00-30 F-3 00-30 Correction = 000-Troubleshooting:1, power does not respond, the screen does not shineCheck whether the is electrically, you can use the same of other electrical appliances to check, if there is electric check the thermostat is turned off, you can press a SET boot2, the screen can be displayed, but can not the temperature control functionIf the temperature is set to the right, but the start does not start, the stop does not stop it is possible to start and stop the set value error, please drop the setpoint and stop value3, the temperature changes beyond the control rangeThe controller for the bit control, that is, when the red light is on, stop when the green light, if the control process changes the light is right, but the temperature overshoot indicates that the thermostat is good, you can reduce your Heating / cooling power can be resolved4, temperature with the actual deviationIf you feel that the current temperature is 30 degrees and the thermostat shows 29.6, you can enter the temperature correction, hold down the SET start temperature to the school can be adjusted to 0.4, if the real-time temperature of 31.2, you Think it is 30 can be reduced correction value adjusted to -1.2 so you can get the temperature you want-The use of Note:This product must be read carefully for the first time1, this product is three plugs must be with the ground socket2, the thermostat host is not waterproof, pay attention to avoid water, is strictly prohibited into the bathroom or outdoor use3, the use of power is strictly prohibited than the product calibration power or cause permanent damage and danger4, the actual temperature control should pay attention to observe whether the correct implementation of temperature control can leave-Package Included:1pcs x 12V/AC 110V-220V Display Digital Temperature Controller Multi-function Temperature Thermostat Control Switch
